IMP 7¼” Kit

Description

Imp. Designed by Colin Edmondson.

Imp is a small but solidly engineered half horsepower 7¼” gauge battery electric loco. Equally at home on a garden railway or trundling round your local club track. It shares the same ingenious bolt together design as the very popular Scamp. Controls are simple, a direction switch, a speed controller, a ‘dead man’s’ foot pedal, which cuts power if the driver isn’t on board, and a handbrake working on all four wheels. It takes only a few moments to detach the heavy battery box, making it a lot easier to transport the Imp in the back of the car when visiting other tracks.
A light duty locomotive and is happy trundling around with one or two carriages. (Actual performance will depend on track conditions, rail type and gradients.) The Imp is a bolt together build.

Measurements:

Length: 540mm | Width: 380mm | Height with slatted seat: 640mm | Height without slatted seat: 475mm  | Minimum radius: 2m | Load: 1 tons on 1 in 100

Imp Kit – £793.00

Optional extra: Slatted seat £79.00

Supplied: All laser cut parts to complete the loco | 2x wheelsets ready to fit | Welded layshaft

Full assembly instructions and shopping list can be found here.

Estimated lead time: 4-6 weeks.

For a personal touch of assistance during your build or breaking in your new stock, join this Facebook group. Filled with current and experienced builders of Colin Edmondson products.
